Cormak Electric Mast Pallet Jack Q10E16 1600mm 1000kg
-
Cormak Electric Mast Pallet Jack Q10E16 1600mm 1000kg
-
Most important advantages:
A solid structure made of high-quality steel provides greater rigidity and stability during lifting. safety switch. Built-in controller to protect the battery from discharging or damaging Sealed maintenance-free AGM batteryBuilt-in charger LED battery charge indicator and "abdominal" safety switch to prevent hitting the operator Speed controller for safe driving and speed limits Turtle Ride Mode Electric lifting and lowering under full operator control Polyurethane wheels and rollers These types of rollers are universal for all types of surfaces. They are characterized by high abrasion resistance and increased resistance to mechanical damage. They guarantee quiet operation and low rolling resistance.
Technical data
|
Maximum lifting height |
1600 mm |
|
Maximum load weight |
1000 kg |
|
Fork length |
1150 mm |
|
Height with lowered forks |
2090 mm |
|
Height with mast lowered |
2090 mm |
|
Fork dimensions |
60x142x1150 mm |
|
Spread forks |
550 mm |
|
Overall width |
790 mm |
|
Total length |
1780 mm |
|
Turning radius |
1390 mm |
|
Rolling speed with load / without load |
3,5 / 4,0 km/h |
|
Lifting speed with load / without load |
0,1 / 0,2 m / s |
|
Descent speed with load / no load |
0,12 / 0,1 m / s |
|
Service brake type |
electromagnetic |
|
Propulsion engine power |
0,75 kW |
|
Lifting motor power |
2 kW |
|
Battery voltage/power |
12V 65Ah 2 units |
|
Weight |
530 kg |
